1965 De Vries Lentsch Custom

Refit Information

Major Reft 2016

Hull and plating:
- 16 new pillars inside the bulwark welded
- Renewal/repair of all vent pipes and inlets on main deck
- Bridge house in front of wheelhouse completely renewed
- Installation of new longitudinal stiffeners to support forward part of wheelhouse roof
- New aluminium panels on access stair to fly bridge
- Renewal of funnel and mast
- Renewal of material around the staircase main deck-sun deck.

Paint and fairing:
- Total dismantling of everything attached to hull, deck and superstructure
- Sandblasting the aluminium superstructure to SA 2.0
- Sandblasting the steel hull to SA 2.0.
- Total new fairing
- Total new Boero paint system respecting specifications and instructions.

Hull openings:
- Sealing all windows, new glass of all windows including wheelhouse
- All 16 portholes have been dismantled, treated and replaced
- Two new fixed windows in mahogany frame on top of the corridor

Propulsion and technical installation:
- New valves on fuel level tubes
- Replacement of part of the fuel piping for certified types
- Revision exhaust valves on hull
- Revision of sea chest and oil exchanger at stabilizers
- Revision of sea chests
- Cleaning oil tanks
- Oil for hydraulic change
- Revision of sealing on shafts and bearing exchange
- Revision steering system
- New pipes for fuel and black water. Tank level indicator in ER and electric gauge in wheelhouse
- Revision of bilge alarms, including check/renewal of valves
- Overhaul of the black water discharge
- New resistors in water heaters
- Overhaul of the general-purpose sea pump
- Overhaul of the four electric pumps in the ER
- Overhaul of 2-stage bilge pumps
- Overhaul of black and grey water pumps
- Overhaul chain washing pump
*All pumps have been totally overhauled on the specialists (Miveme) workbench and bearings and
brushes have been renewed
- Exhaust terminals provided with new fanges
- Installation of two new exhaust gas bellows
- Labelling manifold & pipelines
- Total bilge cleaning
- Normal maintenance such as lube oil, filters lube, filters fuel, fuel separators, air filters, drive belts, gear
boxes lube oil, all impellers have been renewed and/or cleaned.
- Opening and cleaning of all tanks: fuel, fresh water, black and grey
- Replacement of hydraulic lines for Opacmare gangway
- Starboard shower on main deck with cold and hot water
- Air conditioning cleaning and disinfection of fan coils
- Installation schemes of holding tanks and pipelines
- Renewal and certification of the fire-fighting equipment
- Improvement on the AC fan coil system
- Re-organizing of cabling routes in ER

Electrical Installations:
- Installation of new Mastervolt charger 24/80
- Installation of new Opacmare gangway control units
- Two fxed spot lights with teak base on stern
- New searching light on mast
- New fridge, dishwasher and laundry/tumble dryer installed
- New service batteries, 6 x 220 Ah
- New start batteries Flash Power, 2 x 40 Ah

Main engines and gearboxes:
- Main engines and gearboxes rebuilt (zero rated) 2016
- Injectors seals
- Injector pipes
- Injectors
- Engine oil gasket
- Fuel pump overhaul
- Valves base
- Valves leading
- Cylinders heads overhaul
- Renewal of piston rings
- New main bearings and conrod bearings
- New thermostatic valve
- New sealing hydraulic bow thruster and oil change

Steering System:
- Renewal of autopilot steering power motor
- Dismantling of rudderstock

Interior:
- Soft upgrade of total interior, including the crew and galley area
- New cushions in saloon
- New lifting table in saloon
- New carpets throughout the interior

Exterior Woodwork:
- New teak deck: 10 mm teak planks on 6 mm Marine plywood using Sika 298
- New wood parts on handrail, gunwale, upper panels on deck house dinette and corridors, new external deck heads
- New door frame on wheelhouse and galley
- Four new bow seats and lockers
- New cushions over all sunbathing area on top of the wheelhouse
- Teak cup holders on mast
- New wooden name plates
- New steps + ss hand rails from sundeck to flybridge deck

Navigation and Communication Equipment:
- The navcom antennas have been re-arranged and positioned
- The bridge had a soft make over
- Up to date interface of data with the Simrad instruments

Equipment and Miscellaneous:
- Renewal and certification of the safely equipment
- Crane testing
- New mooring lines, 4 x 25 m, diam. 28 mm
- Renewal of passerelle, stanchions and rail rope
- New winter cover for tender
- Supply of ps folding ladder

2018
- New Yamaha Jetski (3 seats) and toys (donut)
- Inspection of all hydraulic pumps including stabilizers
- Overhauling crane
- New Second generator (Kohler silent) - 12EFKOZD-EU (12KW, 1Phase/50hz/1500T/min/12V), Kohler Marine Diesel Alternator 4E5.0b, 1Ph, Brushless - 4Lead 50Hz, 230Volt, 1Ph, 2W Soundshield installed (Rear Connection) Siphon Break Hose Connection - Rear
- Replacement and welding of engine and genset exhausts (under water)
- Water/Gas separator
- New life raft, life vests SOLAS - PLAV d.o.o.
- Replacement of water boiler no 2

2019
- Black and Greywater tank revision, new pumps blackwater, tank monitors, floaters - Gianesschi MV44
- Satellite dome and TV systems new - Trackvision KVH TV6 with autoscan Quad LNB, Gyro sensors, IP box, receiver

2021
- Underwater lights stern - Bluefn LED P24
- Overhaul passerelle hydraulics and wood
- New icemaker with integrated tank, professional food service equipment (stern)

2022
- New cockpit design / new dashboard and control panels / new switchboard (branded name of yacht) new digital instruments / new VHF / new Radar and AIS / new chart plotter / replacement of all navigation equipment
- New windlass (Lofrans), chain galvanization, anchor starboard, digital chain counter
- G5 Wi-Fi
- Big engine service / new injectors / high pressure pumps
