DIMENSIONS
Length overall: 33.7m (110' 7")
Beam: 8.20m (26' 11")
Draught: 2.60m (8' 6")
Displacement: 235 metric tons
Gross tonnage: 271 tons
Net tonnage: 81 tons
CONSTRUCTION
Hull/Superstructure: Steel / Aluminium
Deck material: Teak
External Designer: De Vries Lentsch
Internal Designer: Ken Freivokh Design
CLASSIFICATION & CERTIFICATIONS
Classification Society: Lloyds Register (LR)
Classification Notation:? 100A1 SSC, Yacht Mono, G6
MCA: No
ISM: No
ISPS: No
PERFORMANCE
Maximum Speed: 11.0 knots
Cruising Speed: 10.0 knots
Fuel consumption: 144 L/HR @ 11 knots, 100 L/HR @ 10 knots, 53 L/HR @ 9 knots
Range (nm): 5000nm @ 10kn
TANKAGE
Fuel: 59000
Lubrication oil: 660
Dirty lube oil: 660
Fresh water: 9000
Grey water: 2857
Black water: 2857
MACHINERY
Engines: 2 x CAT 3406
Engine hours: Port: 3,323 and Stbd: 3,303 (since rebuilt in 2017) (2/26/2022)
Generators: 2 x Northern Lights 80 kW
Generator hours: Port: 2,700 and Stbd: 2,586 (since rebuilt in 2017) (2/26/2022)
PROPULSION & STEERING
Steering System: Tenfjord (Rolls Royce) model # JR 2.130
Emergency Steering: Tenfjord
MECHANICAL
Main Engines: 2 x Caterpillar 3406 E @ 480 hp each
Engine Hours: Port – 3,323; Stb – 3,303 (Rebuilt at 8,142 hours)
Gearboxes: Reintjes WAF/LAF 143474
Drive: Direct Drive
Watermaker(s): HEM model # series 30
Marine Air – 192,000 BTU, model # SLGX192, 30kw total heating output
Stabilizers: Quantum Zero Speed model QL 1500
Bow Thruster: Naiad Koop Nautic model # 20” Electrical
Fuel Separator: Alpha Laval model # MIB 303
Filtration: Carbon, UV
Sewage System: Hammond model ABM 25
Fresh Water System: Headhunter model Mach 5 x2
Bilge Water System: Bilge Boy
Helm Control: Rexroth
ELECTRICAL
Output: 400V, 3 phase, 50hz
Generators: Northern Lights, model # mp668HHE, 80kw x 2, Port – 2,700: Stb – 2,586 (Rebuilt at 15,979
– port: 15,983 – stb)
Shore Power: ASEA, 2 x 30 kw, model AC36Tp3
Main Engines Batteries: Sonneschien, model # GS12 160D (196 amp hours x 4, 784 amp hrs total)
Generator Starting Batteries: Sonneschien model # GS12 160D (196 amp hours x 4, 784 amp hrs total)
COMMUNICATION & NAVIGATION EQUIPMENT Communication Systems:
Sat-phone: KVH Fleet One
SatCom(s): Sailor VSAT
Satellite TV System: KVH T6 (NZ & World), In storage: KVH HD7 (US east & WI)
Satcom C: IC-218 (New 2022)
Telephone System: Panasonic model # KXDT521
Cellular WIFI: Pep Wave - Pepmax HD2 dome
All new internet Access points (Ubiquiti Network long range x 8), Feb 2022
SSB: Sailorman
VHF Fixed: Sailorman
Intercom System: Amplidan Commander 1500
Ships Computer: LG - Beelink
Ships Printer: HP Jet Pro 9022
Navigation Systems:
Radar #1: Furuno S Band model # FR2105/
2015/B series with ARPA
Radar #2: Furuno x band 12 kw with ARPA
Autopilot: Pilotstar D
GPS #1: Furuno GP33 (Firmware updated Feb 2022)
GPS #2: Furuno GP33 (Firmware updated Feb 2022)
Plotter Software: TimeZero Nobeltec (Charts updated Jan 2022, incl.US, WI,Med)
Depth Sounder: Blackbox Furuno DFF1
Gyrocompass: Anschutz (serviced Jan 2022)
Magnetic Compass: C. Plath model # 2843
Navtex: Furuno model # NX700
Weather Fax: Sailor model # DT 4646E/Printer: Sailor model # H1252B
Wind Indicator: B&G
Speed Indicator: B&G
Speed Log: BEN Anthea, transducer replaced 2020
ENTERTAINMENT
TV main deck saloon: 1 x Samsung 8K 75”, new Dec 2021
New ultra-quiet custom TV lift in main saloon, new Dec 2021
2 x Yamaha 9-channel AVENTAGE network receiver amplifiers, new Dec 2021
TV skylounge: 1 x Samsung 8K 55”, new Dec 2021
TV Lower deck: 3 x Samsung 24” with Denon Processor amplifiers
Kaleidoscope movie server for main saloon and skylounge, new Dec 2021
Middle Atlantic custom AV racks x 2, new Dec 2021
Apple TV x 2
DVD’s: Sony BlueRay BOP – S1700
DOMESTIC APPLIANCES, EQUIPMENT & LAUNDRY
Range: Miele cook top 5 burners/induction, New Oct 2021
Oven: Gaggenau
Microwave: Galley – Samsung; Crew mess Moulinex
Refrigeration: Cospolich model # R182MSMLML12
(in galley)
Freezer: SubZero 30CI (in galley)
Icemaker(s): ULine in skylounge
Small Fridge: SubZero ICBID30RP
Fridge/Freezer Plant: Custom with Bitzer compressors (in crew mess)
Main Laundry Washer: Miele stackable pw 6065 x 2
Main Laundry Dryer: Miele stackable pt7/35c x 2
ACCOMMODATION
ADYTUM has a large master stateroom forward on main deck with ensuite bathroom and adjoining private office. The main deck saloon has curved sliding doors and can be separated from lobby and entrance to galley and master.Below deck she features a full beam VIP stateroom aft with a large king bed and ensuite bathroom, further forward she has a newly modified king bed stateroom to starboard and a twin bed cabin to port, both with ensuite bathrooms.
The bridge deck has a large skylounge with a dining table that seats 8 pax on starboard side and a bar with three barstools to port. Easy access to aft bridge deck or forward to the wheelhouse.
There are ample outside living spaces with a seating/dining area on aft deck and a round table for dining or entertainment on bridge deck aft plus comfortable sun deck above.
DECK
Anchor Windlass System: Ascon model # ACV20.19E x 2; Aft anchor windlass Muir
Anchors: Poole 270 kg x 2 – foredeck: 90 kg anchor on aft deck
Anchor Chain & Rode: 182 m x 19 mm stud link galvanized chain x 2 on foredeck;
Stern anchor chain: 60 m
Deck Capstans: Ascon CV20.00E
Davit/Cranes: Staalart Techniques 48kmm
Accommodation Ladders: Staalart Techniques
Passarelle: Staalart Techniques
Spotlights: Carlisle & Finch x 2
Exterior Showers: Hansgrohë
Underwater Lights: Sea Vision SV18 LED x 12
PAINT JOB
Hull painted Aristo Blue in 2021- including side boarding ladders Teak caprail stripped and re-varnished in 2021
TENDER & TOYS
2017 Novurania 15’ with 2017 Yamaha F60LB 4-stroke
Note: Subject to change and/or negotiation during the buying process. SAFETY & SECURITY
CCTV System: Hikvision – NVR firmware updated Dec 2021
Cameras: 1080 IP PTZ x 6
Monitors: NEC Multi sync model # LCD 1770bx
Ship Safe(s): Securikey Premiere in master and in captain’s cabin
Fire Fighting Equipment:
Fire/Heat/Smoke Detectors: Throughout – Thorne Security model # T1008/H016
Fixed fire suppression system: Ultrafog, re-certified Dec 2021
Fire Extinguishers x 19, re-certified Dec 2021
Fire Fighting Bunker Gear: Viking – 2 x breathing apparatus sets
Fire Suppression System for Engine Room: Sea Fix BN234, re-certified Dec 2021 + 2 spare bottles
Safety Equipment:
Life Rafts: Duarry 16 person with hydrostatic release x 2, serviced Nov 2021
Life Rings: 4 regular life rings, 2 life rings with smoke & strobe
EPRIB(s): ACR RLB36 cat 1 x 1; Mcmurdo E5 model ADCE428B AL0028D Cat 2
SART: Mcmurdo S4 Rescue SART S4/17 698 77
Flares: Pains Wessex 9506720, Replaced Nov 2021
REFIT LOG
18 page refit log supplied separately
